TSA5511 Datasheet, Synthesizer, Philips

TSA5511 Features

• Synthesizer
• Complete 1.3 GHz single chip system
• Low power 5 V, 35 mA
• I2C-bus programming
• In-lock flag
• Varicap drive disable
• Low radiation

PDF File Details

Part number:

TSA5511

Manufacturer:

Philips

File Size:

145.96kb

Download:

📄 Datasheet

Description:

1.3 ghz bidirectional i2c-bus controlled synthesizer. TSA5511 The TSA5511 is a single chip PLL frequency synthesizer designed for TV tuning systems. Control data is entered via the I2C-

TSA5511 Application

• Applications
• TV tuners
• VCR Tuners ORDERING INFORMATION EXTENDED TYPE NUMBER TSA5511 TSA5511T TSA5511AT Note 1. SOT102-1; 1996 De
