INN3477C
Features
- Primary sensed output OVP
- Open SR FET gate detection
- Hysteretic thermal shutdown
- Input voltage monitor with accurate brown-in/brown-out and overvoltage protection
Full Safety and Regulatory pliance
- Reinforced insulation
- Isolation voltage >4000 VAC
- 100% production HIPOT pliance testing
- UL1577 and TUV (EN60950) safety approved
- Enables designs that have “A” performance criteria for EN61000-4 suite of test standards, including EN61000-4-2, 4-3 (30 V/m), 4-4, 4-5, 4-6, 4-8 (100 A/m) and 4-9 (1000 A/m)
Green Package
- Halogen free and Ro HS pliant
Applications
- Use with Inno Mux for Energy Star 8, CEC, and 2021/2023 EU labeling for monitors and TVs
Description
The Inno Switch™3-MX together with Inno Mux dramatically improves system efficiency by eliminating the boost and buck converter stages. It also simplifies the development and manufacturing of multiple output power supplies, particularly those in pact enclosures or with high efficiency requirements. The Inno...
