PT6525

8-A 5-V/3.3-V Input Adjustable ISR

PT6525 Features

* 8A Rated Output Current

* Single Device: 3.3V/5V Input

* High Efficiency (92% for PT6521)

* Small Footprint (0.75 in², Suffix ‘P’)

* Output On/Off Standby Control

* Output Short-Circuit Protection

* Adjustable Output Voltage

* Soft St

PT6525 General Description

These power modules are a series of high performance, 8-A rated, Integrated Switching Regulators (ISRs), housed in a low cost 14-Pin SIP (Single In-line Package). Operating from either a 3.3V or 5V standard power bus, the PT6520 series produces a high-output, low-voltage power source for the industr.

PT6525 Datasheet (182.93 KB)

Preview of PT6525 PDF

Datasheet Details

Part number:

PT6525

Manufacturer:

Power Trend

File Size:

182.93 KB

Description:

8-a 5-v/3.3-v input adjustable isr.
