Datasheet Details

Part number	P24C128E
Manufacturer	Puya
File Size	790.72 KB
Description	I2C-Compatible Serial E2PROM
Datasheet	P24C128E Datasheet
Additional preview pages of the P24C128E datasheet.

Product details

Description

The P24C128E is 128-Kbit I2C-compatible Serial EEPROM (Electrically Erasable Programmable Memory) device.

Features

Single Supply Voltage and High Speed.
Minimum operating voltage down to 1.7V.
1 MHz clock from 2.5V to 5.5V.
400kHz clock from 1.7V to 2.5V.
Low power CMOS technology.
Read current 100uA, maximum.
Write current 0.5mA, maximum.
Schmitt Trigger, Filtered Inputs for Noise Suppression.
Sequential & Random Read Features.
Page Write Modes, Partial Page Writes Allowed.
Software Write Protection(SWP) for Programmable Block.
Upper q.
