RM3261D

high performance off-line PWM power switch

RM3261D Features

* including Cycle-by-Cycle current limiting,VDD OVP,VDD clamp and UVLO,Excellent EMI perfoemance is achieved with proprietary frequency shuffling technique.high precision constant voltage and constant current can be achieved by RM326X. Otherwise,RM326X is offered in SOP8 and DIP-8 package. RM326X Fea

RM3261D General Description

P Power Supply I Loop compensation for CV stability The voltage feedback from auxiliary winding, connected I to resistor divider from auxiliary winding reflecting output voltage,PWM duty cycle is determined by EA output and current sense signal at PIN 4. I Current sense input O HV MOSFET dr.

RM3261D Datasheet (377.96 KB)

Preview of RM3261D PDF

Datasheet Details

Part number:

RM3261D

Manufacturer:

REACTOR

File Size:

377.96 KB

Description:

High performance off-line pwm power switch.
General Describtion RM326X is a high performance off-line PWM power switch for low power AC/DC charger and adapter applications,It operates in primary.
