CS82C52 Datasheet, Interface, Renesas

CS82C52 Features

• Interface
• Single Chip UART/BRG
• DC to 16MHz (1M Baud) Operation
• Crystal or External Clock Input
• On-Chip Baud Rate Generator - 72 Selectable Baud Rates

PDF File Details

Part number:

CS82C52

Manufacturer:

Renesas ↗

File Size:

1.06MB

Download:

📄 Datasheet

Description:

Cmos serial controller interface. PIN SYMBOL NO. TYPE RD 1 I WR 2 I D0-D7 3-10 I/O A0, A1 11, 12 I IX, OX 13, 14 I/O SDO 15 O GND 16 CTS 17 I DSR
