ISL6292C Li-ion/Li Polymer Battery Charger

ISL6292C Li-ion/Li Polymer Battery Charger The ISL6292C is an integrated single-cell Li-ion or Li-polymer battery charger capable of operating with an input voltage as low as 2.4V. This charger is designed to work with various types of ac adapters. The ISL6292C operates as a linear charger when the ac adapter is a voltage source. The battery is charged in a CC/CV (constant current/constant voltage) profile. The charge current is programmable with an external resistor up to 1.5A. The ISL6292C ca.

ISL6292C Features

* charge current thermal foldback to guarantee safe operation when the printed circuit board is space limited for thermal dissipation. Additional features include preconditioning of an over-discharged battery, automatic recharge, and thermally enhanced DFN package. Ordering Information TEMP. PART #

ISL6292C Datasheet (508.59 KB)
