BH76112HFV Datasheet, Drivers, Rohm

BH76112HFV Features

• Drivers 1) Wide operating voltage range: Vcc = 2.6 V~5.5 V 2) Built-in 8th order LPF 3) Built-in sync-tip clamp circuit 4) Compact HVSOF6 package (3.0 mm × 1.6 mm × 0.75 mm) 5) Built-in standby

PDF File Details

Part number:

BH76112HFV

Manufacturer:

ROHM ↗

File Size:

461.25kb

Download:

📄 Datasheet

Description:

Low current consumption single output video drivers. This video amplifier with built-in LPF uses a full output swing type output stage to make low voltage operation at Vcc = 2.6V possibl

TAGS

BH76112HFV

Rohm
