SDC602 Current Mode PWM Controller

SDC602 Description

Current Mode PWM Controller Datasheet SDC602 General .
Features SDC602 is a high-performance current mode control IC Tdesigned for AC/DC convertor, which supplies about continuous 5W output power at the.

SDC602 Features

* SDC602 is a high-performance current mode control IC Tdesigned for AC/DC convertor, which supplies about continuous 5W output power at the universal AC input CONFIDENTIAL DOCUMENrangefrom85Vto265V.
* Built-in high voltage power transistor of 700V
* Cycle-by-cycle current limit
* Very l

SDC602 Applications

* Offline AC/DC flyback converter
* Adaptor/Charger for cell and other portable Apparatus SDC DIP-8 Figure 1. Package Type December, 2013 Rev. 1.2 ©2013 Shaoxing Devechip Microelectronics Co. , Ltd. 1/11 www. sdc-semi. com Current Mode PWM Controller Datasheet SDC602 Pin Configuration

📥 Download Datasheet

Preview of SDC602 PDF
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
SDC602
Manufacturer
SDC
File Size
341.67 KB
Datasheet
SDC602-SDC.pdf
Description
Current Mode PWM Controller
