SS1348 - Unipolar Hall Switch-Low Sensitivity

Datasheet Summary

Description

The SS1348 is a unipolar Hall-effect sensor IC fabricated from CMOS technology.

The device integrates a voltage regulator, Hall sensor with dynamic offset cancellation system, small signal amplifier, Schmitt trigger and an open-drain output driver.

Features

3.5V to 24V Operation.
-40°C to 150°C Superior temperature operation.
CMOS technology.
Low current consumption.
Chopper-stabilized amplifier stage.
Open drain output.
Low sensitivity.
Small Size SOT23 3L or SIP 3L both RoHS compliant packages Functional Block Diagram.
