ES2ABF - Surface Mount Superfast Recovery Rectifier

ES2ABF Description

ES2ABF THRU ES2JBF Surface Mount Superfast Recovery Rectifier Reverse Voltage - 50 to 600 V Forward Current - 2 A .

ES2ABF Features

* Glass Passivated Chip Juntion

ES2ABF Applications

* Low profile package
* Superfast reverse recovery time SMBF 5.5 5.1 4.4 4.2 3.7 3.5 2.2 1.9 Mechanical Data
* Case: SMBF
* Terminals: Solderable per 1.3 1.1 MIL-STD-750, Method 2026 0.26 0.18 All Dimensions in mm Absolute Maximum Ratings and Characteristics R

📥 Download Datasheet

Preview of ES2ABF PDF
datasheet Preview Page 2

Datasheet Details

Part number
ES2ABF
Manufacturer
SEMTECH
File Size
757.65 KB
Datasheet
ES2ABF-SEMTECH.pdf
Description
Surface Mount Superfast Recovery Rectifier
