RD33EB, RD3.0EB Datasheet - SEMTECH

RD33EB, RD3.0EB, ZENER DIODES

RD2.0E~RD200E ZENER DIODES .
 datasheet Preview Page 1 from Datasheet4u.com

RD3.0EB-SEMTECH.pdf

This datasheet PDF includes multiple part numbers: RD33EB, RD3.0EB. Please refer to the document for exact specifications by model.

Datasheet Details

Part number:

RD33EB, RD3.0EB

Manufacturer:

SEMTECH

File Size:

594.03 KB

Description:

ZENER DIODES

Note:

This datasheet PDF includes multiple part numbers: RD33EB, RD3.0EB.
Please refer to the document for exact specifications by model.

Features

* DHD (Double Heatsink Diode) Construction
* Vz: Applied E24 standard (RD130E to RD200E: 10 volts step).

Applications

* Circuits for Constant Voltage, Constant Current, Waveform clipper, Surge absorber, etc. Absolute Maximum Ratings (Ta = 25 OC) Parameter Power Dissipation Forward Current Reverse Surge Power at t = 10µs Junction Temperature Storage Temperature Range Symbol Ptot IF PRSM Tj TS Value 500 200 100 175
