SS16F, SS12F SURFACE MOUNT SCHOTTKY BARRIER RECTIFIERS

SS16F Description

SS12F THRU SS120F SURFACE MOUNT SCHOTTKY BARRIER RECTIFIERS Reverse Voltage - 20 to 200 V Forward Current - 1 A .

SS16F Features

* Metal silicon junction, majority carrier conduction

SS16F Applications

* Low power loss, high efficiency
* High forward surge current capability
* For use in low voltage, high frequency inverters, free wheeling, and polarity protection applications SMAF 4.4 4.9 3.3 3.7 2.40 2.80 1.3 1.6 1.1 1.3 0.18 Mechanical Data
* Case: SMAF molde

📥 Download Datasheet

This datasheet PDF includes multiple part numbers: SS16F, SS12F. Please refer to the document for exact specifications by model.
datasheet Preview Page 2

Datasheet Details

Part number
SS16F, SS12F
Manufacturer
SEMTECH
File Size
846.94 KB
Datasheet
SS12F-SEMTECH.pdf
Description
SURFACE MOUNT SCHOTTKY BARRIER RECTIFIERS
Note
This datasheet PDF includes multiple part numbers: SS16F, SS12F.
Please refer to the document for exact specifications by model.
