ZPD27B, ZPD2V7B Datasheet - SEMTECH

ZPD27B Silicon Epitaxial Planar Zener Diodes

ZPD2V7BZPD75B Silicon Epitaxial Planar Zener Diodes Max. 0.5 Max. 1.9 Min. 27.5 Black Cathode Band Black Part No. Black "ST" Brand XXX ST Max. 3.9 Min. 27.5 SEMTECHGlass Case DO-35 Dimensions in mm Absolute Maximum Ratings (Ta = 25 OC) Parameter Symbol Value Unit Power Dissipation Ptot 500 1) mW Junction Temperature Tj 175 OC Storage Temperature Range Tstg - 55 to + 175 OC 1) Valid provided that leads are kept at ambient temperature at a distance of 8 mm from case. Char.

ZPD2V7B-SEMTECH.pdf

This datasheet PDF includes multiple part numbers: ZPD27B, ZPD2V7B. Please refer to the document for exact specifications by model.
ZPD27B Datasheet Preview Page 2 ZPD27B Datasheet Preview Page 3

Datasheet Details

Part number:

ZPD27B, ZPD2V7B

Manufacturer:

SEMTECH

File Size:

461.32 KB

Description:

Silicon epitaxial planar zener diodes.

Note:

This datasheet PDF includes multiple part numbers: ZPD27B, ZPD2V7B.
Please refer to the document for exact specifications by model.
