SZ1536

Surface Mount Zener Rectifiers

Image	Manufacturer	B2B MPN	Description	Distributor	Stock	Quantity	Price	Buy Now
	EIC Corporation	SZ1536	Zener Diode Single 36V 5% 50Ohm 1000mW 2-Pin SMA	Verical	15000	5000 units	$0.08	🛒 Buy Now

Download Datasheet (617.71 KB)

SZ1536 Datasheet Preview — Preview of SZ1536 Datasheet

Datasheet Details

Part number:

SZ1536

Manufacturer:

SMD

File Size:

617.71 KB

Description:

Surface mount zener rectifiers.
SZ153D thru SZ15D0 3.3*200 V 1.0 W Surface Mount Zener Rectifiers Reverse Voltage 3.3 to 200 V Po.
wer 1.0 W Features * Plastic package has Underwriters Laboratory Flammability Classification 94 V-0 .

✔ SZ1536 Features

Plastic package has Underwriters Laboratory Flammability Classification 94 V-0
For surface mounted applications
Low Zener impedance
Low regulation factor
High t

✔ SZ1536 Application

Low Zener impedance
Low regulation factor
High temperature soldering guaranteed: 260 °C/10 seconds at
