M54HCT258 QUAD 2-CHANNEL MULTIPLEXER

The M54/74HCT257 and the M54/74HCT258 are high speed CMOS MULTIPLEXERs fabricated with silicon gate C2MOS technology. They have the same high speed performance of LSTTL combined with true CMOS low power consumption. These IC’s are composed of an independent 2channel multiplexer with common SELECT an.

M54/M74HCT257 M54/M74HCT258 HCT257 QUAD 2 CHANNEL MULTIPLEXER (3-STATE) HCT258 QUAD 2 CHANNEL MULTIPLEXER (3-STATE, INVERTING) . . . . . . . HIGH SPEED tPD = 16 ns (TYP.) at VCC = 5 V LOW POWER DISSIPATION ICC = 4 µA (MAX.) at TA = 25 °C COMPATIBLE WITH TTL OUTPUTS VIH = 2V (MIN.) VIL = 0.8V (MAX) OUTPUT DRIVE CAPABILITY 15 LSTTL LOADS SYMMETRICAL OUTPUT IMPEDANCE IOH = IOL = 6 mA (MIN.) BALANCED PROPAGATION DELAYS tPLH = tPHL PIN AND FUNCTION COMPATIBLE WITH 54/74LS257/258 B1R (Plastic Pac.
