PSD301-B-15L Low Cost Field Programmable Microcontroller Peripherals

PSD301-B-15L Features

* SUMMARY s Single Supply Voltage:

* 5 V±10% for PSD3xx, ZPSD3xx, PSD3xxR, ZPSD3xxR

* 2.7 to 5.5 V for ZPSD3xxV, ZPSD3xxRV s s s s s s Figure 1. Packages Up to 1 Mbit of EPROM Up to 16 Kbit SRAM Input Latches Programmable I/O ports Page Logic Programmable Security PLDCC44 (J) CLDCC44

PSD-301.pdf

PSD301-B-15L Datasheet Preview — This datasheet PDF includes multiple part numbers: PSD301-B-15L, PSD. Please refer to the document for exact specifications by model.

Datasheet Details

Part number:

PSD301-B-15L, PSD

Manufacturer:

STMicroelectronics ↗

File Size:

691.81 KB

Description:

Low cost field programmable microcontroller peripherals.

Note:

This datasheet PDF includes multiple part numbers: PSD301-B-15L, PSD.
Please refer to the document for exact specifications by model.
