PSD301-B-15U

Low Cost Field Programmable Microcontroller Peripherals

PSD301-B-15U Features

* SUMMARY s Single Supply Voltage:

* 5 V±10% for PSD3xx, ZPSD3xx, PSD3xxR, ZPSD3xxR

* 2.7 to 5.5 V for ZPSD3xxV, ZPSD3xxRV s s s s s s Figure 1. Packages Up to 1 Mbit of EPROM Up to 16 Kbit SRAM Input Latches Programmable I/O ports Page Logic Programmable Security PLDCC44 (J) CLDCC44

PSD301-B-15U Datasheet (691.81 KB)

Preview of PSD301-B-15U PDF

Datasheet Details

Part number:

PSD301-B-15U

Manufacturer:

STMicroelectronics ↗

File Size:

691.81 KB

Description:

Low cost field programmable microcontroller peripherals.
