TDA7564B

Multifunction Quad Power Amplifier

ST Microelectronics

TDA7564B Features

* Features

* Multipower BCD technology MOSFET output power stage DMOS power output New Hi-efficiency (class SB) High output power capability 4x28W/4Ω @ 14.4V, 1KHZ, 10% THD, 4x50W max, power Max. output power 4x72W/2Ω Full I C bus driving:

* St-by

TDA7564B Datasheet (644.33 KB)

TDA7564B Datasheet Preview — Preview of TDA7564B PDF

Datasheet Details

Part number:

TDA7564B

Manufacturer:

STMicroelectronics ↗

File Size:

644.33 KB

Description:

Multifunction quad power amplifier.
