BALF-112X-01D3 Datasheet, Balun, STMicroelectronics

BALF-112X-01D3 Features

• Balun
• 50 Ω nominal input / conjugate match to CC1120, CC1125
• Low insertion loss
• Low amplitude imbalance
• Low phase imbalance
• Small footprint B

PDF File Details

Part number:

BALF-112X-01D3

Manufacturer:

STMicroelectronics ↗

File Size:

623.00kb

Download:

📄 Datasheet

Description:

50 ohm nominal input / conjugate match balun. STMicroelectronics' BALF-112X-01D3 is an ultra-miniature balun, integrating both matching network and harmonics filter. Matching impe

BALF-112X-01D3 Application

• Applications
• 868 MHz and 928 MHz impedance-matched balun filter optimized for Texas Instruments® CC1120, CC1125, CC1175, CC1200 sub-GHz RF
