Description
The BZW04 TVS series is designed to protect sensitive equipment against electrostatic discharges according to IEC 61000-4-2, MIL STD 883 Method 3015, and electrical overstress such as IEC 61000-4-4 and 5.
Features
- Peak pulse power:.
- 400 W (10/1000 μs).
- up to 2.3 kW (8/20 μs).
- Stand-off voltage range from 5.8 V to 376 V.
- Unidirectional and bidirectional types.
- Operating Tj max: 175 °C.
- High power capability at Tj max. : up to 230 W (10/1000 µs).
- Lead finishing: matte tin plating
Complies with the following standards.
- UL94, V0.
- J-STD-020 MSL level 1.
- J-STD-002, JESD 22-B102 E3 and MIL-STD-750, method 2026.
