DTV1500M - CRT HORIZONTAL DEFLECTION HIGH VOLTAGE DAMPER DIODE

Description

High voltage diode especially designed for horizontal deflection stage in standard and high resolution displays for TV’s and monitors.

This device is packaged in TO-220AC, ISOWATT220AC and TO-220FPAC (insulated package).

Features

  • s 6A 1500 V 1.65 V 135 ns K A s s s s s s High breakdown voltage capability High frequency operation Specified turn on switching characteristics Very fast recovery diode Low static and peak forward voltage drop for low dissipation Insulated package (ISOWATT220AC, TO-220FPAC): Insulating voltage = 2000V DC Capacitance = 12pF Planar technology allowing high quality and best electrical characteristics A K TO-220FPAC DTV1500MFP A K ISOWATT220AC DTV1500MF.

📥 Download Datasheet

Datasheet preview – DTV1500M

Datasheet Details

Part number DTV1500M
Manufacturer STMicroelectronics
File Size 90.08 KB
Description CRT HORIZONTAL DEFLECTION HIGH VOLTAGE DAMPER DIODE
Datasheet download datasheet DTV1500M Datasheet
