HCF4047B, LOW POWER MONOSTABLE/ASTABLE MULTIVIBRATOR

OF B SERIES CMOS DEVICES" DESCRIPTION The HCF4047B is a monolithic integrated circuit fabricated in Metal Oxide Semiconductor technology available in DIP and SOP packages.

The HCF4047B consist of a gatable astable multivibrator with logic techniques incorporated to DIP SOP ORDER CODES PACKAGE TU

HCF4047B LOW POWER MONOSTABLE/ASTABLE MULTIVIBRATOR s LOW POWER CONSUMPTION : SPECIAL CMOS OSCILLATOR CONFIGURATION s MONOSTABLE (one - shot) OR ASTABLE (free-running) OPERATION s TRUE AND COMPLEMENTED BUFFERED OUTPUTS s ONLY ONE EXTERNAL R AND C REQUIRED s BUFFERED INPUTS s QUIESCENT CURRENT SPECIFIED UP TO 20V s STANDARDIZED, SYMMETRICAL OUTPUT CHARACTERISTICS s 5V, 10V AND 15V PARAMETRIC RATINGS s INPUT LEAKAGE CURRENT II = 100nA (MAX) AT VDD = 18V TA = 25°C s 100% TESTED FOR QUIESCENT CURR
