STM32F302K6, STM32F302R6 - ARM Cortex-M4 32-bit MCU + FPU

STMicroelectronics

Datasheet Details

Part number	STM32F302K6, STM32F302R6
Manufacturer	STMicroelectronics
File Size	1.94 MB
Description	ARM Cortex-M4 32-bit MCU + FPU
Datasheet	STM32F302R6-STMicroelectronics.pdf
Note	This datasheet PDF includes multiple part numbers: STM32F302K6, STM32F302R6. Please refer to the document for exact specifications by model.

. 12 3.1 Arm® Cortex®-M4 core with FPU, embedded Flash and SRAM . . 12 3.2.2 Embedded SRAM

Core: Arm® 32-bit Cortex®-M4 CPU with FPU (72 MHz max. ), single-cycle multiplication and HW division, DSP instruction.
Memories.
32 to 64 Kbytes of Flash memory.
16 Kbytes of SRAM on data bus.
CRC calculation unit.
Reset and power management.
VDD, VDDA voltage range: 2.0 to 3.6 V.
Power-on/Power down reset (POR/PDR).
Programmable voltage detector (PVD).
Low-power: Sleep, Stop, and Standby.
VBAT su.
