Part number: STW70N10F4
Manufacturer: STMicroelectronics (https://www.st.com/)
File Size: 582.79KB
Download: 📄 Datasheet
Description: N-CHANNEL MOSFET
Part number: STW70N10F4
Manufacturer: STMicroelectronics (https://www.st.com/)
File Size: 582.79KB
Download: 📄 Datasheet
Description: N-CHANNEL MOSFET
Type
STB70N10F4 STD70N10F4 STP70N10F4 STW70N10F4
VDSS 100 V 100 V 100 V 100 V
RDS(on) max < 0.0195 Ω < 0.0195 Ω < 0.0195 Ω < 0.0195 Ω
ID 65 A 60 A 65 A 65 A
* Ex.
Description
This STripFET™ DeepGATE™ Power MOSFET technology is among the latest improvements, which have been especial.
This STripFET™ DeepGATE™ Power MOSFET technology is among the latest improvements, which have been especially tailored to minimize on-state resistance, with a new gate structure, providing superior switching performance.
3 2 1
TO-247
3 2 1
TO-220
.
Image gallery
