T7815CT PRECISION 1A REGULATORS

STMicroelectronics

T7815CT Description

L7800AB/AC SERIES PRECISION 1A REGULATORS s s OUTPUT CURRENT IN EXCESS OF 1A OUTPUT VOLTAGES OF 5; 6; 8; 9; 12; 15; 18; 20; 24V THERMAL OVERLOAD PROT.
The L7800A series of three terminal positive regulators is available in TO-220, TO-220FP, TO-220FM and D2PAK packages and several fixed output voltage.

T7815CT Applications

* These regulators can provide local on-card regulation, eliminating the distribution problem associated with single point regulation. Each type employs internal current limiting, thermal shut-down and safe area protection, making it essentially indestructible. If adequate heat sinking is provided, t

📥 Download Datasheet

T7815CT Datasheet Preview — Preview of T7815CT PDF

Datasheet Details

Part number: T7815CT
Manufacturer: STMicroelectronics ↗
File Size: 400.82 KB
Datasheet: T7815CT-STMicroelectronics.pdf
Description: PRECISION 1A REGULATORS
