Z7M Datasheet, triacs equivalent, STMicroelectronics

Z7M Features

• Triacs
• On-state rms current, IT(RMS) 1 A
• Repetitive peak off-state voltage, VDRM/VRRM 600 or 800 V
• Triggering gate current, IGT (Q1) 3 to 25 mA Applications

PDF File Details

Part number:

Z7M

Manufacturer:

STMicroelectronics ↗

File Size:

291.57kb

Download:

📄 Datasheet

Description:

Standard 1a triacs. The Z01 series is suitable for general purpose AC switching applications. These devices are typically used in applications such as ho

Z7M Application

• Applications
• AC switching
• Home appliances Description The Z01 series is suitable for general purpose AC switching applications.
