EMM5079ZB Datasheet, Mmic, SUMITOMO

EMM5079ZB Features

• Mmic
• Output Power; P1dB = 24.0 dBm (Typ.)
• High Gain; GL = 23 dB(Typ.)
• Wide Frequency Band ; 10.0
    – 15.4 GHz
• Impedance Matched Zin/Zout = 5

PDF File Details

Part number:

EMM5079ZB

Manufacturer:

SUMITOMO

File Size:

613.68kb

Download:

📄 Datasheet

Description:

X / ku-band power amplifier mmic. The EMM5079ZB is a wide band power amplifier MMIC that contains a four stage amplifier, internally matched, for standard communica

EMM5079ZB Application

• Applications SEDI’s stringent Quality Assurance Program assures the highest reliability and consistent performance. ABSOLUTE MAXIMUM RATING Item
