2SD2390Darlington
Equivalent circuit B
C
(70Ω) E
Silicon NPN Triple Diffused Planar Transistor (Complement to type 2SB1560)
Application : Audio, Series Regulator and General Purpose
sAbsolute maximum ratings (Ta=25°C) sElectrical Characteristics
(Ta=25°C)
Symbol VCBO VCEO VEBO IC IB PC Tj Tstg
Ratings 160 150 5 10 1
100(Tc=25°C) 150
–55 to +150
Unit V V V A A W °C °C
Symbol ICBO IEBO V(BR)CEO hFE VCE(sat) VBE(sat) fT COB
Conditions VCB=160V
VEB=5V IC=30mA VCE=4V, IC=7A IC=7A, IB=7mA IC=7A, IB=7mA VCE=12V, IE=–2A VCB=10V, f=1MHz
Ratings 100max 100max 150min 5000min∗ 2.5max 3.
D2390 Datasheet
