Datasheet Details
Part number:
STR7103, STR7000
Manufacturer:
Sanken ↗ electric
File Size:
240.88 KB
Description:
Separate Excitation Switching
Note:
This datasheet PDF includes multiple part numbers: STR7103, STR7000.
Please refer to the document for exact specifications by model.
Features
* High output current (6A:STR7000 series, 12A: STR7100 series) High efficiency (70 to 90%) Wide DC input voltage range Built-in drooping type overcurrent protection circuit Foldback type overcurrent protection can be set eApplications
* Electronic equipment sLineup VO (V) IO (A) 6 12 5 STR7001+SI-8020 STR7101+SI-8020 12 STR7002+SI-8021 STR7102+SI-8021 15 STR7002+SI-8022 STR7102+SI-8022 24 STR7003+SI-8023 STR7103+SI-8023 sAbsolute Maximum Ratings Power Section: STR7000/STR7100 (Ta=25°C) Parameter Power Transistor BreakdoSTR7103 Distributors
