STR-X6769B Power IC for Quasi-Resonant Type Switching Power Supply

📥 Download Datasheet  Datasheet Preview Page 1

Description

Power IC for Quasi-Resonant Type Switching Power Supply with High Efficiency and Low Noise in Full Load Range STR-X6769B Sep.2013 *General desc.
The STR- X6769B is power IC for quasi-resonant type switching power supply, incorporating a power MOSFET and a controller IC.

📥 Download Datasheet

Preview of STR-X6769B PDF
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Specifications

Part number
STR-X6769B
Manufacturer
Sanken ↗
File Size
887.17 KB
Datasheet
STR-X6769B-Sanken.pdf
Description
Power IC for Quasi-Resonant Type Switching Power Supply

Features

* Quasi-resonant operation mode Achieves the optimal high efficiency and low noise power supply systems.
* Current mode control
* Built-in PWM oscillator The PWM operates with the minimum frequency of around 22kHz, until the quasi-resonant signal becomes valid, reduces the stress on comp
