2SK1420
2SK1420 is N-Channel Silicon MOSFET manufactured by SANYO.
Features
- Low ON-state resistance.
- Ultrahigh-speed switching.
- Converters.
- Micaless package facilitating mounting.
Package Dimensions unit:mm
2063A
[2SK1420]
4.5 10.0 2.8 3.2
3.5 7.2 16.0
18.1 5.6
1.6 1.2
0.75 123 2.55 2.55
Specifications
Absolute Maximum Ratings at Ta = 25˚C
Parameter Drain-to-Source Voltage Gate-to-Source Voltage Drain Current (DC) Drain Current (Pulse)
Symbol
VDSS VGSS
ID IDP
Allowable Power Dissipation
Channel Temperature Storage Temperature
Tch Tstg
Conditions
PW≤10µs, duty cycle≤1% Tc=25°C
Electrical Characteristics at Ta = 25˚C
Parameter
Symbol
Conditions
Drain-to-Source Breakdown Voltage
V(BR)DSS ID=1m A, VGS=0
Zero-Gate Voltage Drain Current
IDSS VDS=60V, VGS=0
Gate-to-Source Leakage Current
IGSS VGS=±20V, VDS=0
Cutoff Voltage
VGS(off) VDS=10V, ID=1m A
Forward Transfer Admittance
| yfs | VDS=10V,...
