Part number:
A1749
Manufacturer:
Sanyo
File Size:
126.70 KB
Description:
2sa1749.
* High fT : fT=400MHz (typ).
* High breakdown voltage : VCEO≥200V min.
* High current.
* Small reverse transfer capacitance and excellent high frequnecy chacateristics : Cre=3.4pF (NPN) , 4.2pF (PNP).
* Complementary 2SA1749 and 2SC4564 types.
* Adoption of FBET process. Pac
A1749
Sanyo
126.70 KB
2sa1749.
