STF25A60

Bi-Directional Triode Thyristor

STF25A60 Features

* Repetitive Peak Off-State Voltage : 600V R.M.S On-State Current ( IT(RMS)= 25 A )

* High Commutation dv/dt

* Isolation Voltage ( VISO = 1500V AC )

* ○ 2.T2 ▼ ▲ ○ 3.Gate 1.T1 ○ TO-220F General Description This device is fully isolated package suitable for AC switching applic

STF25A60 General Description

This device is fully isolated package suitable for AC switching application, phase control application such as fan speed and temperature modulation control, lighting control and static switching relay. This device is approved to comply with applicable requirements by Underwriters Laboratories Inc. .

STF25A60 Datasheet (749.04 KB)

Preview of STF25A60 PDF

Datasheet Details

Part number:

STF25A60

Manufacturer:

SemiWell Semiconductor

File Size:

749.04 KB

Description:

Bi-directional triode thyristor.
