SC4005 Datasheet, Sensor, Semiment

SC4005 Features

• Sensor
• 3.5 to 10.5V wide supply voltage range
• 4.5mA power consumption for 5 VDC
• Output voltage proportional to magnetic flux density
• -40℃ to 150℃ wide a

PDF File Details

Part number:

SC4005

Manufacturer:

Semiment

File Size:

164.14kb

Download:

📄 Datasheet

Description:

Linear hall effect sensor. The SC400X are high performance small versatile linear Hall-Effect devices which are operated by the magnetic field from a permanent

SC4005 Application

• Applications
• Angular sensing
• Position sensing
• Over-current detection
• BLDC motor current monitoring
