2SC4150 Datasheet - Shindengen Electric Mfg.Co.Ltd

2SC4150 Switching Power Transistor

SHINDENGEN Switching Power Transistor LSV Series 2SC4150 (TP12S4) 12A NPN OUTLINE DIMENSIONS Case : ITO-220 Unit : mm RATINGS œAbsolute Maximum Ratings Item Symbol Conditions Ratings Unit Storage TemperatureTstg -55 `150 Ž Junction Temperature Tj 150 Ž Collector to Base Voltage V 60 V CBO Collector to Emitter Voltage V 40 V CEO Emitter to Base Voltage V 7 V EBO Collector Current DC I 12 A C Collector Current Peak I 24 A CP Base Current DC I 2 A B Base Curre.

2SC4150_ShindengenElectricMfg.Co.Ltd.pdf

Preview of 2SC4150 PDF
2SC4150 Datasheet Preview Page 2 2SC4150 Datasheet Preview Page 3

Datasheet Details

Part number:

2SC4150

Manufacturer:

Shindengen Electric Mfg.Co.Ltd

File Size:

396.83 KB

Description:

Switching power transistor.
