SFR80F40PS 400V ULTRA-FAST RECOVERY RECTIFIER

SFR80F40PN/PS/P7/PT is an Ultra-Fast Recovery Diode, fabricated in advanced silicon planar epitaxial technology. The process parameter and the device structure are fine tuned with optimized performance of forward voltage drop and reverse recovery time. Accuracy epitaxial dope control, advanced plana.

SFR80F40PS Features

* 1 2 3 12 3 TO-3P 12 3 TO-247S-3L 1 2 3 TO-3PN 12 3 TO-247-3L

* Ultrafast 60 Nanosecond Recovery Time

* Low Forward Voltage Drop

* Low Leakage Current

* 150C Operating Junction Temperature ORDERING INFORMATION Part No. SFR80F40PN SFR80F40PS SFR80F40P7 SFR80F40P7 Package TO-

SFR80F40PN-SilanMicroelectronics.pdf

SFR80F40PS Datasheet Preview — This datasheet PDF includes multiple part numbers: SFR80F40PS, SFR80F40PN. Please refer to the document for exact specifications by model.

Datasheet Details

Part number:

SFR80F40PS, SFR80F40PN

Manufacturer:

Silan Microelectronics

File Size:

249.28 KB

Description:

400v ultra-fast recovery rectifier.

Note:

This datasheet PDF includes multiple part numbers: SFR80F40PS, SFR80F40PN.
Please refer to the document for exact specifications by model.
