SST39VF6402, SST39VF1601 - (SST39VFxx0x) 16M-Bit / 32M-Bit / 64M-Bit Multi-Purpose Flash Plus

Silicon Storage Technology

SST39VF6402 Datasheet Preview — This datasheet PDF includes multiple part numbers: SST39VF6402, SST39VF1601. Please refer to the document for exact specifications by model.

Datasheet Details

Part number	SST39VF6402, SST39VF1601
Manufacturer	Silicon Storage Technology
File Size	356.18 KB
Description	(SST39VFxx0x) 16M-Bit / 32M-Bit / 64M-Bit Multi-Purpose Flash Plus
Datasheet	SST39VF1601_SiliconStorageTechnology.pdf
Note	This datasheet PDF includes multiple part numbers: SST39VF6402, SST39VF1601. Please refer to the document for exact specifications by model.

SST39VF6402 Product details

Description

16 Mbit / 32 Mbit / 64 Mbit Multi-Purpose Flash Plus SST39VF1601 / SST39VF3201 / SST39VF6401 SST39VF1602 / SST39VF3202 / SST39VF6402 Preliminary Specifications To meet high density, surface mount requirements, the SST39VF160x/320x/640x are offered in 48-lead TSOP and 48-ball TFBGA packages.See Figures 1 and 2 for pin assignments.first.The Program operation, once initiated, will be completed within 10 µs.See Figures 4 and 5 for WE# and CE# controlled Program operation timing diagrams and Fig

Features

Organized as 1M x16: SST39VF1601/1602 2M x16: SST39VF3201/3202 4M x16: SST39VF6401/6402.
Single Voltage Read and Write Operations.
2.7-3.6V.
Superior Reliability.
Endurance: 100,000 Cycles (Typical).
Greater than 100 years Data Retention.
Low Power Consumption (typical values at 5 MHz).
Active Current: 9 mA (typical).
Standby Current: 3 µA (typical).
Auto Low Power Mode: 3 µA (typical).
Hardware.
