DMF3926, DMF3926-000 - Silicon Beamless Schottky Diodes

Skyworks

Datasheet Details

Part number	DMF3926, DMF3926-000
Manufacturer	Skyworks
File Size	476.73 KB
Description	Silicon Beamless Schottky Diodes
Datasheet	DMF3926-000-Skyworks.pdf
Note	This datasheet PDF includes multiple part numbers: DMF3926, DMF3926-000. Please refer to the document for exact specifications by model.

Skyworks beamless diode family is designed for a high degree of device reliability in both commercial and industrial uses.

Mechanically rugged design.
Three barrier heights for optimized mixer performance.
Wide product range: series pair, ring, bridge, and eight-diode rings.
Use in ring or crossover designs in double balanced mixers.
Virtually any LO requirement can be met with choice of barrier height.
100% DC tested on water.
Available on film frame or waffle pack Skyworks Green™ products are compliant with all applicable legislation and are halogen-free. For additional informat.
