D Integrated protection ring against
static discharge
D Low capacitance D Low leakage current D Low forward voltage drop
Mechanical Data
! Case: LL34 (SOD-80) ! Weight: 0.05 grams ! Marking: Cathode Band Only
C
B
A
LL34/ SOD-80
Dim
Min
Max
A
3.30
3.70
B
1.30
1.60
C
0.28
0.50
All Dimensions in mm
Maximum Ratings @ TA = 25°C unless otherwise specified
Parameter
Test Conditions
Reverse voltage
Peak forward surge current Repetitive peak forward current Forward current Junction.
