SSF65R099SFD 650V N-Channel Super-Junction MOSFET

SUPER-SEMI SUPER-MOSFET Super Junction Metal Oxide Semiconductor Field Effect Transistor 650V Super Junction Power MOSFET Gen-Ⅱ With Fast-Recovery SS<.
SJ-FET is new generation of high voltage MOSFET family that is utilizing an advanced charge balance mechanism for outstanding low on-resistance and lo.

SSF65R099SFD-SuperSemiconductor.pdf

SSF65R099SFD Datasheet Preview — Preview of SSF65R099SFD PDF

Datasheet Details

Part number:

SSF65R099SFD

Manufacturer:

Super Semiconductor

File Size:

831.04 KB

Description:

650V N-Channel Super-Junction MOSFET

Features

* Multi-Epi process SJ-FET
* Fast-Recovery body diode
* Extremely Low Reverse Recovery Charge
* 700V @TJ = 150 ℃
* Typ. RDS(on) = 80mΩ
* Ultra Low Gate Charge (typ. Qg = 62.5nC)
* 100% avalanche tested SSF65R099SFD SSP65R099SFD SSW65R099SFD
