B82559A0112A013 Datasheet, inductors, TDK

B82559A0112A013 Features

• Inductors
• Very high rated current
• Extremely low DC resistance
• Very low profile and smallest possible footprint
• Suitable for pick and place processes Applic

PDF File Details

Part number:

B82559A0112A013

Manufacturer:

TDK

File Size:

1.06MB

Download:

📄 Datasheet

Description:

Smt power inductors.

B82559A0112A013 Application

• Applications Energy storage chokes for
• DC/DC converters
• VRM modules
• POL converters Terminals
• Lead-free tinne
