LL1005-FH10NS Datasheet - TOKO

LL1005-FH10NS Multilayer Chip Inductors

Multilayer Chip Inductors LL1005-FH Series TYPE LL1005-FH Series Inductance Range: 1.0~100nH (E-12) Temperature Coefficient of L: + 250ppm/°C typical DIMENSIONS / Length (mm) 1.0 ± 0.1 Width (mm) 0.5 ± 0.1 Thickness (mm) 0.5 ± 0.1 Electrode width A (mm) 0.25 ± 0.1 Marking of polarity: Marking is on the upper Surface of the unit. Marking of polarity Marking: Blue Green L W T A ELECTRICAL CHARACTERISTICS / Inductance Range 1.0~100nH (E-12 Series) <.

LL1005-FH10NS Datasheet (63.46 KB)

Preview of LL1005-FH10NS PDF

Datasheet Details

Part number:

LL1005-FH10NS

Manufacturer:

TOKO

File Size:

63.46 KB

Description:

Multilayer chip inductors.
