TKA0503S, TKA0303D, 1W 3KVDC Isolated Miniature Dual Output DC/DC Converters

TKA Series .
1W 3KVDC Isolated Miniature Dual Output DC/DC Converters The TKA series are miniature, isolated 1W DC/DC converters in a SIP and DIP package.

datasheet Preview Page 1 from Datasheet4u.com

TKA0303D-TOPPOWER.pdf

TKA0503S Datasheet Preview — This datasheet PDF includes multiple part numbers: TKA0503S, TKA0303D. Please refer to the document for exact specifications by model.

Datasheet Details

Part number:

TKA0503S, TKA0303D

Manufacturer:

TOPPOWER

File Size:

622.88 KB

Description:

1W 3KVDC Isolated Miniature Dual Output DC/DC Converters

Note:

This datasheet PDF includes multiple part numbers: TKA0503S, TKA0303D.
Please refer to the document for exact specifications by model.

Features

* RoHS compliant、CE certification UL 94V-0 package material Efficiency up to 83% Internal SMD construction Operating temperature:-40℃ to 105℃ Industry standard pinout Power sharing on output Input voltage :3.3V, 5V,12V,24V Output voltage: ±3.3V, ±5V, ±9V, ±12V, ±15V, ±24V SELECTION GUIDE Part
