OEL9M0085-Y-E Datasheet - TRULY

OEL9M0085-Y-E - OLED

1 C1P 2 C1N 3 C2P 4 C2N Connect to charge pump capacitor.

These pins are not used and should be disconnedted when Vpp is supplied externally.

5 VDD2 3.0 * 4.2V power supply pad for Power supply for charge pump circuit.

6 VSS This is a ground pin 7 VDD1 Power supply input: 1.65 - 3.5V

TRULY SEMICONDUCTORS LTD.

Rev : 0.1 Aug.25, 2012 SPECIFICATION PART NO.

: OEL9M0085-Y-E This specification maybe changed without any notice in order to improve performance or quality etc.

Please contact TRULY Semiconductors LTD.

OLED R&D department for update specification and product status before design for this product or release the order.

TRULY SEMICONDUCTORS LTD.

P.1 / 19 TRULY SEMICONDUCTORS LTD.

Rev : 0.1 Aug.25, 2012 PRODUCT CONTENTS n PHYSICAL DATA n ABSOLUTE MAXIMUM RATINGS n
