DTA114YE - PNP Digital Transistor

Product Overview

Taiwan Semiconductor

Part number	DTA114YE
Manufacturer	Taiwan Semiconductor
File Size	121.54 KB
Description	PNP Digital Transistor
Datasheet	DTA114YE Datasheet
Note	This datasheet PDF includes multiple part numbers: DTA114YE, DTA114YM. Please refer to the document for exact specifications by model.
Additional preview pages of the DTA114YE datasheet.

Built-in bias resistors enable the configuration of an inverter circuit without connecting external input resistor.
The bias resistors consist of thin -film resistors with complete isolation to allow negative biasing of the input. They also have the advantage of almost completel yeliminating parasitic effects.
Only the on/off conditions need to be set for operation,marking device design easy.
Green compound (Halogen free) with suffix "G" on packing code and prefix "G" on date.
