MB8S - 0.8 Amp Surface Mount Single Phase Bridge Rectifiers

Name: MB8S
SKU: MB8S-762905

Thinki Semiconductor

The MB8S by Thinki Semiconductor is a 0.8 Amp Surface Mount Single Phase Bridge Rectifiers. Below is the official datasheet preview.

Datasheet Details

Part number	MB8S
Manufacturer	Thinki Semiconductor
File Size	323.92 KB
Description	0.8 Amp Surface Mount Single Phase Bridge Rectifiers
Datasheet	MB8S_ThinkiSemiconductor.pdf
Additional preview pages of the MB8S datasheet.

.275(7)MAX .193(4.9) .177(4.5) Plastic package has Underwriters Laboratory Flammability Classification 94V-0 Glass passivated chip junctions High surge overload rating: 35A peak Saves space on printed circuit boards High temperature soldering guaranteed: 260oC/10 seconds. .106(2.7) .090(2.3) .165(4.2) .031(0.8) .019(0.5) .150(3.8) .051(1.3) .067(1.7) .035(0.9) .014(0.35) .006(0.15) Maximum Ratings Case: Molded plastic body over passivated junctions Terminals: Plated lea.
