XC6214 Datasheet - Torex Semiconductor

XC6214 CMOS Low Power Consumption

CMOS Low Power Consumption : 8μA (TYP.) Maximum Output Current : More than 500mA Current Limit Circuit Built-In Thermal Shutdown Circuit Built-In Ceramic Capacitor Compatible SOT-89-, SOT-26 Packages APPLICATIONS DVD, CD-ROM, HDD drive equipment Portable AV equipment (Cameras, VCRs, etc.) Wireless Communication equipment (Mobile & Cordless phone, etc.) Desktop computers, Note book computer, PDAs Network equipment (Wireless LAN etc.)

XC6214 Features

* a voltage reference, an error amplifier, a current limiter, a thermal protection circuit, and a phase compensation circuit plus a driver transistor. The output voltage is selectable in 100mV increments within the range of 1.5V to 5.0V. (Output voltage 1.5V, 1.8V, 2.5V, 3.0V and 3.3V are standard pro

XC6214_TorexSemiconductor.pdf
