XD6121 Datasheet, Detector, Torex

XD6121 Features

• Detector Detect Voltage Range (Standard) : 1.6V, 2.2V, 2.3V, 2.4V, 2.9V, 3.0V, 3.1V, 4.4V, 4.5V, 4.6V Hysteresis Width : VDFL x 5% (TYP.) Operating Voltage Range : 1.0V ~ 6.0V Detect Volta

PDF File Details

Part number:

XD6121

Manufacturer:

Torex

File Size:

854.35kb

Download:

📄 Datasheet

Description:

Voltage detector. The XD6121/XD6122/XD6123/XD6124 series is a group of high-precision, low current consumption voltage detectors with watchdog function

XD6121 Application

• Applications
• Microprocessor watchdog monitoring and reset circuits
• Memory battery backup circuits
• System power-on reset
