TC74AC05FN, TC74AC05F Datasheet - Toshiba Semiconductor

TC74AC05F_ToshibaSemiconductor.pdf

This datasheet PDF includes multiple part numbers: TC74AC05FN, TC74AC05F. Please refer to the document for exact specifications by model.
TC74AC05FN Datasheet Preview Page 2 TC74AC05FN Datasheet Preview Page 3

Datasheet Details

Part number:

TC74AC05FN, TC74AC05F

Manufacturer:

Toshiba ↗ Semiconductor

File Size:

238.61 KB

Description:

Hex inverter.

Note:

This datasheet PDF includes multiple part numbers: TC74AC05FN, TC74AC05F.
Please refer to the document for exact specifications by model.

TC74AC05FN, TC74AC05F, HEX INVERTER

www.DataSheet4U.com TC74AC05P/F/FN TOSHIBA CMOS Digital Integrated Circuit Silicon Monolithic TC74AC05P,TC74AC05F,TC74AC05FN Hex Inverter (open drain) The TC74AC05 is an advanced high speed CMOS INVERTER fabricated with silicon gate and double-layer metal wiring C2MOS technology.

It achieves the high speed operation similar to equivalent Bipolar Schottky TTL while maintaining the CMOS low power dissipation.

Pin configuration and function are the same as the TC74AC04, but the TC74AC05 has high

TC74AC05FN Features

* High speed: tpz = 3.4 ns (typ.) at VCC = 5 V Low power dissipation: ICC = 4 µA (max) at Ta = 25°C High noise immunity: VNIH = VNIL = 28% VCC (min) Symmetrical output impedance: IOL = 24 mA (min) Capability of driving 50 Ω DataSheet4U.com transmission lines. Wi
